Product Advantages of LP Reverse Osmosis RO Membranes:
- Low energy consumption while maintaining high water production and high salt rejection
- Membrane sheets use an oxidation-free treatment process, ensuring stability and long service life
- Suitable for a wide range of water quality conditions and temperature environments
Low Pressure Reverse Osmosis Membrane Operating Conditions
- Maximum Pressure for a Reverse Osmosis membrane: 41 bar (600 psi)
- Maximum Operating Temperature: 45°C (113°F)
- Maximum Pressure Drop per Membrane Element: 1.0 bar (15 psi)
- Continuous Operation pH Range: 2–11
- Chemical Cleaning pH Range: 1–13
- Maximum Feed Water SDI (SDI15): 5.0
- Maximum Free Chlorine Concentration: <0.1 ppm
Notes:
- Flow per membrane element may vary, but the variation does not exceed ±15%
- Variation in effective membrane area does not exceed ±4%
- Stable reverse osmosis desalination membrane rejection is generally measured after 24–48 hours of continuous operation, depending on feed water quality and operating conditions
APPLICATION
Suitable for desalination of feed water with TDS of 2,000–8,000 ppm
- Surface water
- Reclaimed water
- wastewater.
This reverse osmosis RO membrane can be applied for pure water production
- Textiles
- Petrochemicals
- Chemicals
- Beverages
- Electronics.
MODEL
| Type | Membrane Model | Active Area Ft(m3) | Flux gpd(m3/d) | Minimum Rejection | Stablized Rejection Rate(%) | Pressure psi(MPa) | Solution NaCL(ppm) | Recovery |
|---|---|---|---|---|---|---|---|---|
LP |
LP-4040-82 |
82(7.6) |
2,050(7.8) |
99.3 |
99.5 |
225(1.55) |
2000 |
15 |
LP |
LP-8040-400 |
400(37) |
10,500(40) |
99.3 |
99.5 |
225(1.55) |
2000 |
15 |
Test Conditions: 1.55 MPa (225 psi), 25°C (77°F), 2000 ppm NaCl, pH 8, Recovery 15%
DETAILS
CHINA SUPPLIERS STATUS
According to the forecast by the China Membrane Industry Association, the total output value of China’s membrane industry exceeded USD 50 billion in 2022, is expected to reach USD 70 billion by 2025, and USD 82 billion by 2027.
With strong policy support and growing market demand, domestic reverse osmosis (RO) membranes are expected to achieve further improvements in technology, production capacity, and reverse osmosis ro membrane market share, showing a clear trend toward import substitution.
Overall, China’s brackish water reverse osmosis membrane sector is experiencing rapid development. Domestic manufacturers have made significant progress in R&D, production capacity, and competitiveness, and are expected to gain a larger share in the global market in the coming years.
